HT Audio Products

Welcome! This page contains an overview of each of our audio products. Use the following links to jump directly to a product of interest or use the scroll bar to browse through them all.

       BassBox 6 Pro
       BassBox 6 Lite
       X•over 3 Pro
       Woofer Tester 2
       HT Typeface Collection

There are several ways to obtain more information:

  1. Click on the Details link of a product to view an in-depth illustrated description.
  2. Click on the FAQs link of a product to view a list of Frequently Asked Questions.
  3. Click on the Support link of a product to view an index of technical notes.
  4. Download or view a PDF of our audio product brochure. (Adobe Reader is required.)


BassBox Pro.   $149.00*   Details  |  FAQs  |  Support
BassBox Pro is a state-of-the-art speaker enclosure design program. It is used around the world by professional and amateur speaker system designers to design worldclass speaker boxes. BassBox Pro is very versatile and can be used to design speakers for a wide variety of applications including home hi-fi, home theater, car, truck, van, pro sound reinforcement, recording studio monitors, stage monitors, PA, musical instruments, etc.

BassBox Pro.

  • Compatible with Microsoft Windows† 11, 10, 8.1, 8 and 7.
  • The easy-to-use "Design Wizard" helps new users with simple box designs.
  • Includes the world's largest driver database with the parameters for thousands of woofers. Drivers can be added, edited or deleted and a variety of search methods are provided.
  • Many different speaker box types are supported, including: closed boxes, vented boxes, vented boxes with an external active 2nd-order high-pass equalization filter (B6), single-tuned and double-tuned bandpass boxes with two or three chambers, and passive radiator boxes.
  • Speaker designs can be evaluated with up to nine different performance graphs.
  • Acoustic data for the driver and the listening space can be imported from several popular measurement systems.
  • An "expert mode" is available to automatically evaluate driver parameters and spot errors.
  • Includes a built-in test procedure for measuring the parameters of drivers and passive radiators (some test equipment is required).
  • The effects of an external passive network can be included in the response graphs. This can be imported from an X•over Pro crossover network design file.
  • Handles multi-driver, isobaric and bessel designs with a variety of wiring options.
  • Handles dual-voice coil drivers with separate parameters for each voice coil wiring method.
  • Creates and prints box drawings and box parts lists.
  • Includes both "balloon" help and extensive context-sensitive on-screen help.
  • Includes an extensive on-screen manual with tutorials and sample BassBox Pro designs.
  • Includes a thorough and beautifully illustrated 364 page printed User Manual (shown below).
  • Available on CD only (not available for download).

BassBox Pro–Lite Comparison

The BassBox Pro User Manual and CD-R.

$$$ SAVE $29: Purchase both BassBox Pro and X•over Pro for only $239.00*.


BassBox Lite.   $79.00*   Details  |  FAQs  |  Support
BassBox Lite is a streamlined or "Lite" version of BassBox Pro, our premier speaker box design program, without a driver database. It offers 85% of the most powerful features of the Pro version while using a condensed user interface that combines the graphs with the main window.

BassBox Lite.

  • Compatible with Microsoft Windows† 11, 10, 8.1, 8 and 7.
  • Speaker box design is as easy as 1-2-3: First, enter the driver parameters. Second, calculate the box volume and tuning. Third, evaluate the performance with up to nine different performance graphs.
  • Many different box types are supported, including: closed boxes, vented boxes, vented boxes with an external active 2nd-order high-pass equalization filter (B6), single-tuned and double-tuned bandpass boxes with two or three chambers, and passive radiator boxes.
  • An "expert mode" is available to automatically evaluate driver parameters and spot errors.
  • Handles multi-driver and isobaric designs with a variety of wiring options.
  • Handles dual-voice coil drivers with separate parameters for each voice coil wiring method.
  • Creates and prints box drawings and box parts lists.
  • File compatibility with BassBox Pro allows designs to be exchanged between the Pro and Lite versions.
  • Includes both "balloon" help and extensive context-sensitive on-screen help.
  • Includes an extensive on-screen manual with tutorials and sample BassBox Lite designs.
  • Available on CD only (not available for download).

BassBox Pro–Lite Comparison

The BassBox Lite CD case and CD-R.

X•over Pro.   $119.00*   Details  |  FAQs  |  Support
X•over Pro is an innovative passive network design program. It can help you design a 2-way or 3-way passive crossover network, a high-pass, band-pass or low-pass filter, an impedance equalization network, an L-pad and a series or parallel notch filter. With its internal Thiele-Small modeling engine and impedance equalization, X•over Pro provides professional results without requiring you to make complex measurements of each driver.

X•over Pro.

  • Compatible with Microsoft Windows† 11, 10, 8.1, 8 and 7.
  • A variety of 1st, 2nd, 3rd and 4th-order filter types are available.
  • X•over Pro's driver impedance equalization networks can compensate for closed or vented box impedance.
  • Dissimilar driver sensitivities can be equalized with L-pads.
  • Designs simple series and parallel notch filters.
  • Includes the world's largest driver database with the parameters for thousands of woofers and hundreds of midrange drivers and tweeters. Drivers can be added, edited or deleted and a variety of search methods are provided.
  • Crossover network designs can be evaluated with up to four performance graphs. All graphs can include the full system response—including the box response.
  • Driver and box parameters can be imported from a BassBox Pro or BassBox Lite speaker design file.
  • Capacitor ESR and inductor DCR can be estimated for several component types.
  • Includes a handy parallel-series value calculator.
  • Includes a convenient component color value decoder.
  • Creates and prints schematics and parts lists.
  • Includes both "balloon" help and extensive context-sensitive on-screen help.
  • Includes an extensive on-screen manual with introductory sections for beginners.
  • Includes a beautifully illustrated 243 page printed User Manual (shown below).
  • Available on CD only (not available for download).

The X•over Pro User Manual and CD-R.

$$$ SAVE $29: Purchase both BassBox Pro and X•over Pro for only $239.00*.


Woofer Tester 2    Details  |  available from Smith & Larson Audio
The Woofer Tester 2 (WT2) by Smith & Larson Audio is an affordable tool that measures the Thiele-Small (T-S) parameters of speaker drivers with professional precision. In addition to woofers, it can also measure many midrange drivers and tweeters. It is equally "at home" on a test bench with a desktop PC or in the field with a notebook PC.

Woofer Tester 2

  • Comprised of two parts: (1) a test module that connects to the USB port of your computer and (2) software to control the test module. It is a self-contained system that requires no additional components for T-S measurement.
  • The test module is small, very portable, and is powered by the USB port (no batteries or AC adapter are required or provided).
  • Has a current source drive with a continuously adjustable sinewave output from 1 Hz to 20 kHz and can measure impedance and phase with an accuracy of 0.01 ohm and 0.1 degree.
  • Many tests can be initiated with just a single button click such as the "Q, Fs test", "Vas Test", and "Vented Box" test.
  • Can measure and simulate Rem/Xem frequency-dependent reactance.
  • Can measure resistors, inductors and capacitors. In addition to measuring their primary characteristic (resistance, inductance or capacitance) the "meter readings" also displays the separate "real" and "imaginary" values so you can also determine the DCR of an inductor and the ESR of a capacitor.
  • Can measure the inductance of speaker cables and test leads.
  • Can measure the non-linearity of T-S parameters versus the drive level.
  • Includes a line-level output which can be connected to a power amplifier (not included) to "exercise" drivers to break in their suspension prior to T-S parameter measurement.
  • Includes a "Design Air Core Inductor" software tool to help you design an air-core inductor.
  • Can estimate the area (Sd) or effective diameter (diam) of an oval driver. (This is needed when measuring the Vas.)
  • Provides a driver and box simulator along with a "Data Overlay" graph to aid with driver design/repair and basic enclosure simulation. The box simulator includes Qport, Qbox, Qleak and Qloss parameters for various kinds of losses. The simulator also includes a basic "room boost" function.
  • Results can be output to a variety of different files, including a "BassBox" parameter file that BassBox Pro and X•over Pro can read.
  • Can be adjusted for varying atmospheric conditions, including the temperature, relative humidity and air pressure.
  • Includes the WT2 measurement module with USB cable, two test leads with alligator clips on one end, a banana jack with 10-ohm calibration resistor, and CD with WT2 software.

Woofer Tester 2


HT Typeface Collection   $39.00*   Details  |  FAQs  |  Support
The HT Typeface Collection is a collection of four audio font sets: "HT Audio Stuff", "HT Speakers", "HT Microphones" and "HT Schematic". They can help draw attention to your printed materials by adding high-quality graphics and symbols to your promotional materials, flyers, reports, proposals and letters.

  • Compatible with Microsoft Windows† 11, 10, 8.1, 8 and 7.
  • The "HT Audio Stuff" font includes an assortment of miscellaneous audio symbols, icons and labels.
  • The "HT Speakers" font includes various loudspeaker symbols and icons.
  • The "HT Microphones" font includes various microphone symbols and icons.
  • The "HT Schematic" font includes various electrical circuit symbols which allow you to layout and print a simple schematic drawing without a drawing or CAD program.
  • Both TrueType? and Adobe Postscript? formats are provided.
  • A key map for each font set and installation instructions are included.
  • The HT Typeface Collection License Agreement allows the font sets to be installed on up to five computers as long as they are all owned or leased by the licensee.
  • Available on CD only (not available for download).



*All prices are in U.S. dollars and do not include shipping and handling charges, sales tax, import duties or bank transfer fees.

†Only full versions of Microsoft Windows are supported. Windows 11 S and 10 S, the slimline or S-Mode versions designed for low-end computers and tablets, are not supported. Windows RT, the tablet version of Windows 8.x, is not supported.



how to purchase Please see our Purchase page for a list of BassBox and X•over distributors, including links to their websites. Please see our Harris Tech Direct page for direct sales
of all of our products, excluding the Woofer Tester 2.

support policy Technical support is provided for one year to users who have purchased a software license and registered their license with us. Our preferred method of support is email. For more information, visit our Support page.

BassBox update Latest BassBox Pro maintenance release:
  6.0.23  27-Feb-2020.
Latest BassBox Lite maintenance release:
  6.0.11  27-Feb-2020.

X•over update Latest X•over Pro maintenance release:
  3.0.19  27-Feb-2020.

driver database update Latest driver database update: 27-Feb-2020.

HT Merge update Latest HT Merge utility maintenance release:
  1.0.9  06-May-2007.
